RBCTDTMF8VP

Connector DT Series Female 8 Way from panel

GT150 Connector male 4 way
Errebi code: 57802
Producer code: DT04-08PA-L012
Producer: Deutsch
Read moreShow less
€4.18 (tax excl.)
€5.10 (tax incl.)

Discounts for quantities

Quantity Unit price You Save
10 €4.60 €5.03
25 €4.08 €25.43
50 €3.82 €63.75
100 €3.31 €179.00
250 €2.81 €573.07
500 €2.55 €1,274.90
1000 €2.29 €2,807.33
Last items in stock 35 Items
Condition
New
Reference:
RBCTDTPM8VPL012GR
Brand:
Deutsch
Add to wishlist
Description
Number of positions: 8 positions
Pitch: 9.12mm
Gender: Female
Maximum wire diameter: 14 AWG
Minimum wire diameter: 20 AWG
Fixing hole diameter: 1.5mm
Color: Grey
Rated current: 13A
Height: 23.88 mm
Degree of protection: IP68, IP6K9K
Insulation: isolated
Length: 45.67 mm
Material: plastic
Maximum operating temperature: + 125 C
Minimum operating temperature: - 55 C
Mounting angle: straight
Number of lines: 2 lines
Product Type: Automotive Connectors
Lead spacing: 4.45mm
Type: 8 way
Rated voltage: 250V
Width: 36.45 mm
Unit weight: 23 g
Read moreShow less
Product Details
RBCTDTPM8VPL012GR

Data sheet

Product type
Connector body
Serie
DT
Amperage
13A
Material
PA (Polyamide, Nylon)
Color
Grey
IP rating
IP68
Operating temperature
-55°C to +125°C
Dimensions
45.67x36.45x23.88 (L x W x H)
Flammability
94-HB
Voltage
250V
Mounting
On panel
Kind
Male + Female
Number of poles
8
Number of rows
2
Pitch
9.12 mm
Orientation
180°
Minimum order quantity
1
Unit Type
piece
