RBCTMFPF3VSM

Micro Fit Connector male 3 way single row Molex

Errebi code: 26744
Producer code: 43645-0300
Producer: Molex
Read moreShow less
€0.58 (tax excl.)
€0.71 (tax incl.)

Discounts for quantities

Quantity Unit price You Save
5 €0.71 €0.00
10 €0.64 €0.70
25 €0.57 €3.53
50 €0.53 €8.85
100 €0.46 €24.84
250 €0.39 €79.52
500 €0.35 €176.90
1000 €0.32 €389.53
Available in stock 472 Items
The minimum purchase order quantity for the product is 5.
Condition
New
Reference:
RBCTMFPF3VSM
Brand:
Molex
Add to wishlist
Description
Circuits (maximum): 3
Color - Resin: Black
Flammability: 94V-0
Glow Wire Compatible: No
Key on the coupling part: None
Lock on the mating part: Yes
Material: nylon resin
Net weight: 0.456 / g
Number of lines: 1
Panel Mount: No
Pitch - Mating interface: 3.00mm
Polarized to the mating part: Yes
Stackable: No
Temperature range - Operating from: -40 ° to + 105 ° C
Read moreShow less
Product Details
RBCTMFPF3VSM

Data sheet

Product type
Connector body
Serie
Micro-Fit 3.0 - 43645
Amperage
5A
Material
PA (Polyamide, Nylon)
Color
Black
Operating temperature
-40°C to +105°C
Dimensions
14,00x9,85x8,28 (L x W x H)
Flammability
94V-0
Voltage
600V
Mounting
For cable
Kind
Female
Number of poles
3
Number of rows
1
Pitch
3.00 mm
Orientation
180°
Minimum order quantity
5
Unit Type
pieces

Specific References

UPC
800754366175
