RBCTMNFPM3VNRM.UL

Connectors Mini Fit male 3 way black

Errebi code: 48483
Producer code: 172646-0312
Producer: Molex
Read moreShow less
€2.34 (tax excl.)
€2.85 (tax incl.)

Discounts for quantities

Quantity Unit price You Save
10 €2.57 €2.85
25 €2.28 €14.27
50 €2.14 €35.69
100 €1.86 €99.92
250 €1.57 €321.17
500 €1.43 €713.70
1000 €1.28 €1,570.14
Available in stock 8096 Items
Condition
New
Reference:
RBCTMNFTPM3VNRM.UL
Brand:
Molex
Add to wishlist
Description
Product Name: Mini-Fit Jr.
Series: 172646
Circuits (maximum): 3
Number of Rows: 1
Color - Resin: Black
Material - Resin: Nylon
Flammability: 94V-2
Gender: Plug
Glow-Wire Capable: Yes
Keying to Mating Part: None
Lock to Mating Part: Yes
Panel Mount: Yes
Pitch - Mating Interface: 4.20mm
Pitch - Termination Interface: 4.20mm
Polarized to Mating Part: Yes
Stackable: No
Temperature Range - Operating (°C): -40° to +105°
Read moreShow less
Product Details
RBCTMNFTPM3VNRM.UL

Data sheet

Product type
Connector body
Serie
Mini-Fit
Amperage
13A
Material
PA (Polyamide, Nylon)
Color
Black
IP rating
IP20
Operating temperature
-40°C to +105°C
Flammability
94V-2
Mounting
For cable
Kind
Male
Number of poles
3
Number of rows
1
Pitch
4.20 mm
Orientation
180°
Minimum order quantity
1
Unit Type
piece

Specific References

UPC
887191725680
Attachments
048483_001_3D .pdf
Download (163.18KB)
048483_002_Drawing.pdf
Download (102.94KB)
