Connector Ampseal series 16 male 2x2 way

Connector Ampseal series 16 male 2x2 way

Errebi code: 66124
Producer code: 776487-1
Producer: TE/Connectivity
Read moreShow less
€5.28 (tax excl.)
€6.44 (tax incl.)

Discounts for quantities

Quantity Unit price You Save
10 €6.07 €3.68
25 €5.71 €18.41
50 €4.51 €96.62
100 €4.05 €239.24
250 €3.59 €713.25
500 €3.22 €1,610.40
'Available in 30 working days from the order.'
Condition
New
Reference:
RBCTAS16PF2X2V
Brand:
TE Connectivity
Add to wishlist
Description
Manufacturer: TE Connectivity
Number of positions: 4 positions
Pitch: 5.3mm
Gender: Male
Red
Fixing hole diameter: 1.5mm
Rated current: 13A
Flammability rating: UL 94 HB
Height: 26.8mm
Housing Material: Polybutylene Terephthalate (PBT)
Ingress protection: IP67
Length: 25.33mm
Material: Plastic
Maximum operating temperature: +125 C
Minimum operating temperature: - 40 C
Mounting Angle: Straight
Number of lines: 2 lines
Rated voltage: 250V DC
Width: 36.7mm
Conductor cross section: 14 AWG to 20 AWG
Unit Weight: 16g
Read moreShow less
Product Details
RBCTAS16PF2X2V

Data sheet

Minimum order quantity
1
Unit Type
piece
