RBCTNFPF4X2VM

Connectors Nano Fit male 4x2 way

Errebi code: 30004
Producer code: 105308-1208
Producer: Molex
Read moreShow less
€1.06 (tax excl.)
€1.29 (tax incl.)

Discounts for quantities

Quantity Unit price You Save
5 €1.29 €0.00
10 €1.17 €1.28
25 €1.04 €6.45
50 €0.97 €16.17
100 €0.84 €45.39
250 €0.71 €145.32
500 €0.65 €323.30
1000 €0.58 €711.91
Available in stock 784 Items
The minimum purchase order quantity for the product is 5.
Condition
New
Reference:
RBCTNFPF4X2VM
Brand:
Molex
Add to wishlist
Description
Series: 105308
Overview: Nano-Fit Power Connectors
Product Name: Nano-Fit
Circuits (maximum): 8
Color - Resin: Black
Flammability: 94V-0
Gender: Receptacle
Glow-Wire Capable: Yes
Keying to Mating Part: Yes
Lock to Mating Part: Yes
Material - Resin: Nylon
Number of Rows: 2
Panel Mount: No
Pitch - Mating Interface: 2.50mm
Pitch - Termination Interface: 2.50mm
Polarized to Mating Part: Yes
Temperature Range - Operating (°C): -40° to +105°, -40° to +115°
Current - Maximum per Contact: 6.5A
Read moreShow less
Product Details
RBCTNFPF4X2VM

Data sheet

Product type
Connector body
Serie
Nano-Fit - 105308
Amperage
6.5A
Material
PA (Polyamide, Nylon)
Color
Black
Operating temperature
-40°C to +105°C
Dimensions
15,70x12,70x10,04 (L x W x H)
Flammability
94V-0
Mounting
On cable
Kind
Male
Number of poles
8
Number of rows
2
Pitch
2.50 mm
Orientation
180°
Minimum order quantity
5
Unit Type
pieces

Specific References

UPC
889056023733
Attachments
030004_001_3D .pdf
Download (198.72KB)
030004_002_Drawing.pdf
Download (382.28KB)
