Push button microswitch B3F 12x12 PCB

Errebi code: 25026
Producer code: B3F-4055
Producer: OMRON

Read moreShow less

€0.34 (tax excl.)

€0.41 (tax incl.)

Discounts for quantities

Quantity	Unit price	You Save
5	€0.41	€0.00
15	€0.37	€0.61
30	€0.33	€2.48
55	€0.31	€5.70
105	€0.27	€15.29
255	€0.23	€47.55
505	€0.21	€104.74
1005	€0.19	€229.49

Available in stock 1368 Items

The minimum purchase order quantity for the product is 5.

Condition

New

Reference:

RBMIP12X12CS

Brand:

OMRON

Add to wishlist

Description
Product Details

Description

Illuminated: Non-Illuminated
Illumination Colour: -
Lamp Type: -
Mounting Style: Through Hole
Mounting Direction: Straight
Stem Height: 7.3 mm
Actuator: Rectangular
Operating Force: 2.5 N
Current Rating: 50 mA
Voltage Rating DC: 24 VDC
Voltage Rating AC: -
Ground Terminal: Yes
Contact Form: SPST
Termination Style: Solder Pin
Length: 12 mm
Width: 12 mm
Height: 3.5 mm
Series: B3F
Operating Temperature(°C): -25° a +70°
Product Type: Tactile Switches
Unit Weight: 850 mg

Push button microswitch B3F 12x12 PCB
