Connector terminal block to carriage 3,81 pitch Female 16 Way Green
ErreBi code: 21823
Producer code: SH16-3,81
Producer: EuroClamp
Read moreShow lessProducer code: SH16-3,81
Producer: EuroClamp
€3.23
(tax excl.)
€3.94
(tax incl.)
Condition
New
Reference:
RBMRST16VP3.81
Brand:
Add to wishlist
Generality
- Pitch: 3.81 mm
- Body height: 11.10 mm
- Body depth: 15.50mm
- Size class: medium
- Conductor section: 2.5 mmq / 14 AWG
- Cable entry section: 1.8 × 2.6 mm
- Cable stripping: max 8 mm
- Working temperature: -40 ° C ÷ + 130 ° C
Electrical characteristics
- Current: 11A
- Voltage: 160V
- Pulse voltage: 2,5 kV
Mechanical characteristics
- Screw: M2
- Maximum torque: 0.25÷0.27 Nm / 2.3÷2.5 Lb-in
Materials
- Insulating body: PA - UL 94 V0
- Screw: Galvanized steel
- Clamp / spring: Nickel-plated copper alloy
- Terminal: Copper alloy
Read moreShow less
- Pitch: 3.81 mm
- Body height: 11.10 mm
- Body depth: 15.50mm
- Size class: medium
- Conductor section: 2.5 mmq / 14 AWG
- Cable entry section: 1.8 × 2.6 mm
- Cable stripping: max 8 mm
- Working temperature: -40 ° C ÷ + 130 ° C
Electrical characteristics
- Current: 11A
- Voltage: 160V
- Pulse voltage: 2,5 kV
Mechanical characteristics
- Screw: M2
- Maximum torque: 0.25÷0.27 Nm / 2.3÷2.5 Lb-in
Materials
- Insulating body: PA - UL 94 V0
- Screw: Galvanized steel
- Clamp / spring: Nickel-plated copper alloy
- Terminal: Copper alloy
RBMRST16VP3.81
Data sheet
- Product type
- Terminal
- Amperage
- 11A
- Material
- PA (Polyamide, Nylon)
- Color
- Green
- Operating temperature
- -40°C to +130°C
- Dimensions
- 15,50x60,96x11,10 (L x W x H)
- Flammability
- 94V-0
- Voltage
- 160V
- Contact material
- Copper Alloy
- Mounting
- On cable
- Wire range
- 2.50 mmq
- Kind
- Female
- Number of poles
- 16
- Number of rows
- 1
- Pitch
- 3.81mm
- Orientation
- 180°
- Contact plating
- Nickel
- Minimum order quantity
- 1
- Unit Type
- piece
