Errebi code: 58875Producer code: B04B-XASK-1-A (LF) (SN)Producer: Japan Solderless Terminals
XA Connector male 3 way retainer mountable
Errebi code: 20393
Producer code: XAP-03V-1
Producer: Japan Solderless Terminals
Read moreShow lessProducer code: XAP-03V-1
Producer: Japan Solderless Terminals
€0.49
(tax excl.)
€0.60
(tax incl.)
Condition
New
Reference:
RBCTXAPF3V
Brand:
Add to wishlist
Contact Termination Type: Crimp
Gender: Plug
No. of Contacts: 3
No. of Rows: 1
Pitch Spacing: 2.5mm
Contact Plating: Tin
Contact Material: Brass
SVHC: No SVHC (16-Jun-2014)
Colour: Natural (White)
Connector Mounting Orientation: Cable
Contact Resistance Max: 10mohm
Contact Termination: Crimp
Current rating: 3A
External Depth: 6.9mm
External Width: 9.8mm
Flammability rating: UL94V-0
Height: 9.5mm
Insulation Resistance: 1000Mohm
Material: Nylon 6.6
Operating Temperature Max: 85°C
Operating Temperature Min: -25°C
Termination Method: Crimp
Voltage Rating V AC: 250V
Voltage Rating V DC: 250V
Wire Size AWG Max: 20AWG
Wire Size AWG Min: 28AWG
Withstand Voltage: 1000VAC
Read moreShow less
Gender: Plug
No. of Contacts: 3
No. of Rows: 1
Pitch Spacing: 2.5mm
Contact Plating: Tin
Contact Material: Brass
SVHC: No SVHC (16-Jun-2014)
Colour: Natural (White)
Connector Mounting Orientation: Cable
Contact Resistance Max: 10mohm
Contact Termination: Crimp
Current rating: 3A
External Depth: 6.9mm
External Width: 9.8mm
Flammability rating: UL94V-0
Height: 9.5mm
Insulation Resistance: 1000Mohm
Material: Nylon 6.6
Operating Temperature Max: 85°C
Operating Temperature Min: -25°C
Termination Method: Crimp
Voltage Rating V AC: 250V
Voltage Rating V DC: 250V
Wire Size AWG Max: 20AWG
Wire Size AWG Min: 28AWG
Withstand Voltage: 1000VAC
RBCTXAPF3V
Data sheet
- Product type
- Connector body
- Serie
- XA
- Amperage
- 3A
- Material
- PA66 (Polyamide 66, Nylon 66)
- Color
- White
- Operating temperature
- -25°C a +85°C
- Flammability
- 94V-0
- Voltage
- 250V
- Kind
- Male
- Number of poles
- 3
- Number of rows
- 1
- Pitch
- 2.50 mm
- Minimum order quantity
- 20
- Unit Type
- pieces
