Minimodul Connector male 7 way
Errebi code: 15413
Producer code: 3114-07
Producer: Lumberg
Read moreShow lessProducer code: 3114-07
Producer: Lumberg
€0.51
(tax excl.)
€0.62
Condition
New product
Reference:
RBCTMNMPF7V
Brand:
Series: Minimodul
Connector Type: Wire
Number of Contacts: 7
Length: 20mm
Environmental conditions
- Temperature range: -25 °C/+100 °C
Materials
- Insulating body: PBT, V-0 according to UL94
Electrical data (at Tamb 20 °C)
- Rated current: 5.0 A (Tamb 30 °C) (UL AWG 22–20), 2.5 A (Tamb 70 °C) (UL AWG 26–24)
- Rated voltage: 125 V AC (UL 120 V AC) (every chamber equipped), 250 V AC (every other chamber equipped)
Read moreShow less
Connector Type: Wire
Number of Contacts: 7
Length: 20mm
Environmental conditions
- Temperature range: -25 °C/+100 °C
Materials
- Insulating body: PBT, V-0 according to UL94
Electrical data (at Tamb 20 °C)
- Rated current: 5.0 A (Tamb 30 °C) (UL AWG 22–20), 2.5 A (Tamb 70 °C) (UL AWG 26–24)
- Rated voltage: 125 V AC (UL 120 V AC) (every chamber equipped), 250 V AC (every other chamber equipped)
RBCTMNMPF7V
Data sheet
- Product type
- Connector body
- Serie
- Minimodul
- Amperage
- 5A
- Material
- PBT (Polybutylene terephthalate)
- Color
- Black
- Operating temperature
- -25°C a +100°C
- Dimensions
- 15,90x20,00x5,00 (L x W x H)
- Flammability
- 94V-0
- Voltage
- 250V
- Mounting
- On cable
- Kind
- Male
- Number of poles
- 7
- Number of rows
- 1
- Pitch
- 2.50 mm
- Orientation
- 180°
- Minimum order quantity
- 3
- Unit Type
- pieces
