RBCTASF23VCSGRD

Connector AmpSeal female 23 way grey PCB

Kit Connector MTW Series Female 2 Way
Errebi code: 60306
Producer code: 1-776228-4
Producer: TE/Connectivity
Read moreShow less
€10.36 (tax excl.)
€12.64 (tax incl.)

Discounts for quantities

Quantity Unit price You Save
6 €11.84 €4.82
11 €9.23 €37.51
26 €8.23 €114.75
101 €7.22 €547.13
201 €6.42 €1,250.17
'Available in 30 working days from the order.'
Condition
New
Reference:
RBCTASF23VCSGRD
Brand:
TE Connectivity
Add to wishlist
Description
Number of positions: 23 positions
Pitch: 4 mm
Gender: Female
Contact plating: gold
Color: Grey
Contact type: Pin
Rated current: 17A
Features: mounting flange, sealed
Flammability classification: UL 94 V-0
Housing material: polybutylene terephthalate (PBT)
Degree of protection: IP6K9K
Length: 60.8mm
Material: plastic
Maximum operating temperature: + 125 C
Minimum operating temperature: - 40 C
Mounting angle: straight
Number of lines: 3 lines
Product Type: Automotive Connectors
Nominal voltage: 250 VAC
Width: 32.1 mm
Unit weight: 23.587 g
Read moreShow less
Product Details
RBCTASF23VCSGRD

Data sheet

Product type
Connector body
Serie
AmpSeal
Amperage
17A
Material
Plastic
Color
Grey
Operating temperature
-40°C to +125°C
Dimensions
60.80x37.90x32.10 (L x W x H)
Flammability
94V-0
Voltage
250V
Mounting
Printed circuit
Kind
Female
Number of poles
23
Number of rows
3
Pitch
4.00 mm
Orientation
180°
Minimum order quantity
1
Unit Type
piece
